Max. scaling range
-100~+60 dp ℃
Linear accuracy(working range of dew point : -60~+60 dp ℃)
±2 dp ℃ (at +25 ℃) ± (0.02%F.S/℃)
Output signal
standard RS-485 & 1 analogue output
0~20mA / 4 ~ 20 mA / 0~1VDC / 0~5VDC / 0~10VDC
Signal connection
3-wire
Load resistance
current output : max. 500Ω / voltage output : min. 10KΩ
Output calibration(ZERO & SPAN)adjustment range
software
Power supply
8~35VDC/10~30VAC
Protect degree
body IP : 65 (probe : IP 20)
