Measuring range
temp. : -40~+200℃(as request) ; humidity : 0～100%RH；dew point : -40~+60 dp ℃
Accuracy (at 25℃)
temp. : ±0.15℃±0.002℃ x tactual
humidity(0%~90%) : nonlinear error : ± 1.2 % RH；hysteresis error : ± 0.8 % RH；repeatability error : ± 0.4 % RH
humidity(90%~100%) : ± 2 % RH
Thermal sensitivity Temperature error : 0.05 % RH / ℃
Output
0~20mA/4~20mA/0~1V/0~5V/0~10V
Signal Connection
3-wire
Load Resistance
Current output : max. 500Ω
Voltage output : min. 10KΩ
Output Calibration ( zero & span ) adjustment range
software；keyboard
Power Supply
8~35VDC/12~30VAC
Protection Degree
body : IP67 ；probe : IP20
